temperature sensor ntc 10k temperature monitor dishwasher temperature sensor

FOB Reference Price:Get Latest Price
$0.25 - $1.50 / Pieces | 100 Piece/Pieces (Min. Order)
Customization:
customized size (Min. Order: 5000 Pieces)
customized parameter (Min. Order: 5000 Pieces)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
EXSENSE
Model Number:
TS104F25C3950A-ML150
Usage:
Temperature Sensor
Theory:
Resistance Sensor
Output:
Analog Sensor
resistance:
100k ohms
accuracy:
1%-10%
lead wire:
CP leads, PVC, Teflon
lead length:
1000mm
head material:
metal
dissipation factor:
2-4
thermal time constant:
5-20s
shape:
ring lug
Application:
washing machine, dishwasher
Type:
NTC temperature sensor
Supply Ability
Supply Ability:
100000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Anti-static bag/box
Port
Shenzhen, Guangzhou

temperature sensor ntc 10k dishwasher machine temperature controlling sensor





Products Features

1. Short response teim, high delicacy

2.Good coherence and interchnge capability, high precision of resistance and B-value

3.Double packaging technics, good quality of insulation and package,high capability of colliding and bending,high stability

4.Customized specification

5.Operating temperature:-40-200degC

Dimention





Parameters



Resistance
Item No.TS1043950A-ML-300
Rated resistance (at 25C)5K, 10K, 15K, 20K, 50K, 100K, 200K, etc.
Resistance accuracy0.1C, 0.2C, 1%, 2%, 3%, 5%
B-value (25/50 or 25/85)3380K, 3435K, 3450K, 3470K, 3950K, 4050K, 4100K, 4250K
B-value accuracy1%, 2%, 3%, 5%
Operating temperature-40-200C
Response time1-20 sec
Rated power10mW
Material
Epoxy bead diameterφ3.7*19+φ6.0*7 Cu/Ni
Wire length40-3000mm
Wire materialUL2651#26AWG
Wire typeTwin or single
ConnectorXH-2Y   white

If All parameters is not suitable for you, we can custom made.



Wires:

No.WireSpecifications
1PVCUL2651 26AWG    105DegC
2TeflonUL10362 26AWG    250DegC
3XlPEUL3266 26AWG    150DegC
4SiliconUL3122 26AWG    200DegC
All wire can be custom made as customer requirements ,eg. environment, temperature range



Application

1.washing machine





 Related products:


Our Advantages



1. The most importance in side the temprature sensor is NTC chip, it is also manufactured by our factory.

2. We would control the qualtiy

3. We have some tesing bofofore shippment, such as aging testing, pulling testing,temperautre cycling experiment,high temperautre and low temperature testing etc.



Our Services



All parameters could be custom design.

Service standards: we are committed to providing a high quality,and responsive services to all clients

The fastest reply: detailed informations, specific model and price of products will be provided quickly after receiving your inquiry.

Quality assurance: good quality is assured by advanced manufacturing technology. And all products will be checked by our quality-control manager.

OEM available




FAQ



Q: Are you trading company or manufacturer ?

A: We are manufacturer with about 10 years making NTC temperature sensor.



Q: Can products custom made?

A: Yes, of course, our products are totally custom made as customer requirements.

Q: How long is your delivery time?

A: Generally it is 7-15 working days

Q: Do you provide customized samples for free?

A: Yes, before bulk, we will offer samples for testing.



Package
